DEFIBTECH Lifeline View DDU-2300

Defibtech Lifeline View DDU-2300 Features

The Defibtech Lifeline View DDU 2300 is a semi-automatic external defibrillator. The Defibtech Lifeline View comes with a color display screen, showing step-by-step guidance for performing CPR with visual and voice instructions. Additional features on the AED include an option to switch between compression-only CPR and both compression and rescue breathing. The Defibtech Lifeline View runs extensive self-testing daily to make sure that everything is working properly and ready. It’s compact, portable, and lightweight with a rugged design to withstand demanding environments.

  • Videos with corresponding text and voice instructions.
  • Counts beats during the CPR period.
  • Frequent and automatic self-tests: Daily, weekly, monthly, and quarterly.
  • Non-escalation Biphasic Waveform: Adult 150 Joules; Child / Infant: 50 Joules.
  • Durable: 1.2 meter drop tested.
  • Dust protected, spray and water resistant (rated IP55).
  • Lightweight: Less than 3 pounds.

Defibtech Lifeline View DDU-2300 Specifications

Dimensions

  • Height: 9.5” (24 cm)
  • Width: 7.3” (18.5 cm)
  • Depth: 2.3” (5.8 cm)
  • Weight: 3 lbs (1.4 kg)

Defibrillator

  • Type: Semi-automatic external defibrillator
  • Model: DDU-2300
  • Waveform: Biphasic Truncated Exponential (Impedance compensated)
  • Energy: Adult: 150 Joules; Child / Infant: 50 Joules (Nominal into 50 Ohm load)
  • Controls: Lighted On/Off button; Lighted Shock button
  • Charge Time: Less than 4 seconds (from shock advised)
  • Display: High-resolution color LCD
  • Video Prompts: Full motion video; On-screen text prompts
  • CPR Coaching: Video and voice coaching; On-demand video help
  • Voice Prompts: Extensive voice prompts guide user through operation of the unit
  • Rescue Protocol: AHA/ERC (default); supports protocol updates by the user (password protected)

Patient Analysis System

  • Patient Analysis: Automatically evaluates patient impedance for proper pad contact. Monitors signal quality and analyzes patient ECG for shockable / non-shockable rhythms.
  • Sensitivity / Specificity: Meets or exceeds IEC-60601-2-4 requirements; meets AAMI DF80 requirements and AHA recommendations

Battery Pack

  • Model: DBP-2003 (standard); DBP-2013 (aviation; TSO C-142a)
  • Power: 12V, 2800 mAh
  • Type: Lithium/Manganese Dioxide Disposable, recyclable, non-rechargeable
  • Capacity: 125 shocks or 8 hours continuous operation
  • Standby Life: 4 years
  • Low Battery Indicators: Visible; Audible

Self Tests

  • Automatic: Automatic daily, weekly, monthly and quarterly circuitry tests
  • Battery Insertion: System integrity test on battery insertion
  • Pad Presence: Pads preconnected tested daily
  • User-Initiated: Unit and battery pack system test initiated by the user
  • Status Indication: Visual and audible indication of unit status
  • Status Screen: Unit self-test results Pads and battery information (status and expiration)
